Description
Key Feature
• Multi-Zone Climate Control: This 35000 BTU concealed ducted mini split AC provides powerful and balanced heating and cooling across 4 zones. The outdoor unit features chassis electrical heating to ensure reliable operation in tough weather with -13℉ low ambient heating and 131℉ high ambient cooling.
•Significant Energy Savings: The advanced inverter technology maintains steady temperatures with less energy waste, helping reduce cycling and improve comfort. With a 22.5 SEER2 rating and R454B refrigerant, this multi zone split air conditioner and heat pump system is built for efficient year-round use.
• Multiple Control Options: This wifi enabled ducted mini split ac unit allows you to use the included remote, wall thermostat, smart app or voice commands for simple daily operation. It is compatible with Alexa and Google Assistant. The 24H timer allows for scheduled operation, while the child lock keeps settings secure.
• All-season Companion: There are 7 modes for you to choose from: auto, cool, heat, dry, heat, fan, ECO, sleep, along with 8 fan speeds for precise comfort. The 4D auto swing improves room coverage, while self-clean function helps keep air paths fresher over time.
• Quiet Operation & Wide Use: This multi-zone air conditioner and heater runs with low sound levels as low as 28 dB, offering a peaceful environment for busy households and workplaces. It is ideal for household & light commercial use, including living room, bedroom, office, restaurant and more. Note: Professional installation is required.
About this item
•Adjust temperature independently across 4 zones for optimal comfort
•Inverter technology maintains steadier temperatures with smarter energy use
•R454B refrigerant supports more responsible, forward-looking operation
•Built-in versatility for every situation with 7 modes and 8 fan speeds
•Enjoy peaceful sleep without distractions with sleep mode and screen off function
•Effortless convenience with smart control options and wifi connectivity
•Chassis electrical heating ensures reliable performance in colder conditions
•Ideal for homes, offices, and light commercial spaces
•4D auto swing for balanced and even air distribution
•Ducted design keeps your space neat and discreet
•Self-clean function makes maintenance a breeze
•24-hour timer for set-and-forget scheduling
•Child lock helps prevent unwanted changes
Product Dimensions
Specifications
| Color | White |
| Material | Cold-rolled Steel Sheet, Copper, Aluminum |
| Indoor Unit Dimensions | . |
| 9K | 27.56″ x 17.8″ x 7.87″ |
| 12K | 27.56″ x 17.8″ x 7.87″ |
| 18K | 36.22″ x 17.8″ x 7.87″ |
| 24K | 43.31″ x 17.8″ x 7.87″ |
| Outdoor Unit Dimensions | . |
| 18K | 36.5″ x 14.96″ x 27.52″ |
| 27K | 38.5″ x 16.57″ x 31.61″ |
| 35K | 42.28″ x 18.43″ x 33.58″ |
| Multi Zone Combination | 4 |
| Voltage | 208-230V |
| Frequency | 60Hz |
| Temperature Setting Range | 60℉~88℉ |
| Refrigerant | R454B |
| Indoor Unit Noise Level | 28 dB |
| Max Remote Control Distance | 39.2 ft |
| Coverage Area-9K | 450 Sq.Ft |
| Coverage Area-12K | 750 Sq.Ft |
| Coverage Area-18K | 1250 Sq.Ft |
| Coverage Area-24K | 1500 Sq.Ft |
| Dehumidification Capacity-9K | 55.8 Pints/Day |
| Dehumidification Capacity-12K | 81.2 Pints/Day |
| Dehumidification Capacity-18K | 111.6 Pints/Day |
| Dehumidification Capacity-24K | 131.9 Pints/Day |
| Maximum Air Flow Volume-9K | 335 CFM/570 m³/h |
| Maximum Air Flow Volume-12K | 360 CFM/610 m³/h |
| Maximum Air Flow Volume-18K | 500 CFM/850 m³/h |
| Maximum Air Flow Volume-24K | 741 CFM/1260 m³/h |
| 18K SEER2 | 24 |
| 27K SEER2 | 24 |
| 35K SEER2 | 22.5 |
| 18K HSPF2 | 10.5 |
| 27K HSPF2 | 10.5 |
| 35K HSPF2 | 10 |
| Diameter of Liquid Pipe | 1/4″ |
| Diameter of Gas Pipe-9K | 3/8″ |
| Diameter of Gas Pipe-12K | 3/8″ |
| Diameter of Gas Pipe-18K | 1/2″ |
| Diameter of Gas Pipe-24K | 5/8″ |
| Net Weight of 18K(Outdoor Unit) | 92.6 lbs |
| Net Weight of 27K | 119 lbs |
| Net Weight of 35K | 145.5 lbs |
| Net Weight of 9K | 33.1 lbs |
| Net Weight of 12K | 33.1 lbs |
| Net Weight of 18K(Indoor Unit) | 39.7 lbs |
| Net Weight of 24K | 50.7 lbs |
| Package Includes | 1 x Outdoor Unit, 4 x Indoor Unit |
| 4 x Copper Connection Pipe – Gas Pipe | 4 x Copper Connection Pipe – Liquid Pipe |
| 4 x Communication Wire, 4 x Drain Hose | 4 x Remote Control & Holder |
| 4 x Wall Thermostat, 4 x Wall Sleeve | 8 x Tape, 8 x Putty, 4 x Screw Kit |
| 8 x Wall Cap, 4 x Mounting Foot Pad | 9 x User Guide |
